BK7 Wedge Prisms
Material:BK7
Diameter Tolerance:+0.0/-0.1mm
Angular Tolerance:<30
Thickness Tolerance:±0.15mm
Surface Accuracy:λ/10@632.8nm
Surface Quality:60-40
Clear Aperture:>90%
Bevelling:<0.2×45°
Coating:AR
        A:350-650nm
        B:650-1050nm
        C:1050-1580nm
Download
BK7 Wedge Prisms
NO. Dia(mm) T(mm) Deviation Wedge Angle
41N810 25.4mm 4.72 3°53′
41N811 25.4mm 6.43 7°41′
41N812 25.4mm 8.11 11°22′
41N813 25.4mm 9.74 14°52′
41N814 25.4mm 11.33 10° 18°9′
