Fused Silica Negative Meniscus Spherical Lenses
Material:UV-Grade Fused Silica
Design Wavelength:587.6nm
Focal Length Tolerance:±1%
Diameter Tolerance:+0.0/-0.1mm
Thickness Tolerance:±0.1mm
Surface Accuracy:λ/4@632.8nm
Surface Quality:40-20
Centration:<3'
Clear Aperture:>90%
Bevelling:<0.2×45°
Coating:UV AR:290-370nm
Download
Fused    Silica    Negative Meniscus Spherical Lenses
NO. EFL(mm) Dia(mm) Radius(mm) Tc(mm) Te(mm) BFL(mm)
12F4938R -100.00 25.40 (R1)34.89(R2)150.00 3.00 4.90 -102.70
12F4370R -150.00 25.40 (R1)46.86(R2)150.00 3.00 4.20 -153.02
12F4624R -200.00 25.40 (R1)56.49(R2)150.00 3.50 4.40 -203.89
12F4348R -300.00 25.40 (R1)71.23(R2)150.00 3.50 4.10 -304.63
12F4706R -500.00 25.40 (R1)106.23(R2)200.00 3.50 3.90 -505.18
12F4986R -1000.00 25.40 (R1)180.58(R2)300.00 4.00 4.20 -1006.96
12F4315R -100.00 50.80 (R1)37.01(R2)200.00 5.00 13.40 -104.25
12F4101R -150.00 50.80 (R1)50.77(R2)200.00 5.00 10.20 -154.64
12F4328R -200.00 50.80 (R1)62.38(R2)200.00 5.00 8.80 -205.04
12F4929R -300.00 50.80 (R1)88.17(R2)250.00 5.00 7.40 -305.35
12F4329R -500.00 50.80 (R1)129.27(R2)300.00 5.00 6.40 -506.08
12F4246R -1000.00 50.80 (R1)180.39(R2) 300.00 5.00 5.70 -1008.71
